Environmental Friendly 3 Layers Paper Straw Machines High Speed

Name: Environmental Friendly 3 Layers Paper Straw Machines High Speed
Brand: Fect
Price: 1 USD

Quality Environmental Friendly 3 Layers Paper Straw Machines High Speed for sale

Brand Name : Fect

Model Number : PF-80 paper straw machine

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : FOB US $27200.00 - 27300.00 / Set

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 90 sets per month

Delivery Time : within 35 working days after payment confirmed

Packaging Details : Wooden case / High Speed 3 Layers Eco Friendly Environmental Paper Straw Machine

Product name : High Speed 3 Layers Eco Friendly Environmental Paper Straw Machine

Paper Layer : 3 layers

Paper straw Inner Diameter : 3.5-12 mm

Minimum Length : 90 millimetre

Wall Thickness : 0.5-1.5 mm

Speed : Up to 100 m / min

Rewinding Noses : Two noses / single belt

Cutting methods : Pneumatic blades

Machine Gluing way : Single/Double face or no glue

Length fixation : Encoder

Machine Speed control : Servo

Operator person : ONE person

Contact Now

High Speed 3 Layers Eco Friendly Environmental Paper Straw Machine

paper straw machine

This machine is suitable for producing different sizes of paper straws and very small paper tubes. It adopts PLC controller; the main motor is equipped with frequency conversion speed control; touch screen human-machine interface. Easy parameter setting and operation. The cutting part adopts digital multi-knife cutting system. The servo synchronous tracking cutting system makes it more accurate and the multi-knife cutting makes it more efficient. The machine body and main parts are made of stainless steel, no need to paint. It ensures the hygiene and environmental protection of the product.

High Speed 3 Layers Eco Friendly Environmental Paper Straw Machine

1. Adapt to PLC and man-machine interface, the paper straw machine is very easy to operate.
2. World-class quality electrical accessories are used. The straw machine has a long service life.
3. With stainless steel body and protective cover. Finished paper straws are clean and safe.
4. Equipped with an infrared dryer to improve the dryness and hardness of paper straws.
5. Multi-knife cutting system ensures high productivity. With these rollers, the cutting distance can be easily adjusted.

Technical Parameter of paper straw machine

Surace Layer paper roll thickness 60gsm, middle & inner layer is 120gsm

If you need printed paper straw, only need to print the 60gsm thickness paper roll.

Paper Roll can be coated with Wax as per your requirements.

The proportion of paper roll and glue is 1000kgs paper roll: 150kgs glue.

One ton paper roll can do around 850000pcs of paper straw.

It is water base glue, must be food grade.

Technical Parameter
Paper Layer	3 layers
Inner Diameter	3.5-12 mm
Min. Length	90 mm
Wall Thickness	0.5-1.5
Speed	Up to 100 m/min.
Rewinding Noses	Two noses/single belt
Cutting method	Pneumatic blades
Gluing way	Single/Double face or no glue
Length fixation	Encoder
Way of shaft fixing	Pushing
Speed control	Servo
Operator	1 person
Power input	3*380V
Measurement & Weight
Main machine size	351112651800mm
Area space	5000*5000mm
Wheel hub diameter	215 mm
Wheel hub height	125 mm
Min. tread	320 mm
Max. tread	500 mm
Weight	1700kgs

Drive system
Main power	3.0 kw
Max. Rotate speed of wheel hub	200 r/min
Output torque	68 N.m
Drive of wheel hub	2 wheel drive
Bearing	NSK

Control system
PLC Controller	Delta
Man-machine interface	Weinview
Servo system	Delta
Actuator	Schneider
Signal components	Omron
Pneumatic component	Airtac
Synchronism control	Servo Flying Cutting system
Synchronous tracking cutting system	Electronic cam flying shear servo system

Outfit assembly
Tube holder	Standard
Belt angle adjusting	Hand wheel adjustment
Belt tension adjusting	Hand wheel adjustment
Stop when paper break	Standard
Auto glue feeding	Diaphragm pump
Lubrication	Electric roller
Paper tension control	Constant tension control
Paper reel stand type	Automatic paper receiving
Belt	Film baseband
